PUMPS INSTALLATION AND
APPLICATIONS
These pumps are suitable for handling
clean water which are not chemically aggressive to the pump
components.
They are extremely reliable,simple to use,
quiet and virtually maintence-free, finding many uses in
domestic and civil applications,and in particular the
automatic distribution of water from small and medium-sized
surge tanks, transferring water,watering gardens,etc.
PERFORMANCE
¡ù ample and stable
characteristic curves;
¡ù outputs having good absolute
values and tendencially flat curves;
¡ù flat absorption
curves at high delivery rates,preventing motor overloading
even during prolonged use;
¡ù good suction capacities both
at low and high delivery rates.
STRUCTURAL CHARACTERISTICS
¡ù cast iron
pump body
¡ù stainless steel pump body cover
¡ù
stainless steel mechanical seal (graphite to ceramic)
¡ù
brass impeller with centrifugal radial flow type
¡ù Hi-Cr
plated 45# steel shaft
¡ù protection IP44
¡ù with
thermal overload protector in single phase motor
¡ù NSK
bearing or local bearing
WARRANTY:1 YEAR(according to our general sales
conditions)
FLOW RATE Q
PUMP MODEL |
POWER |
Q
m3/h |
0 |
0.6 |
1.2 |
1.8 |
2.4 |
3.0 |
3.6 |
4.2 |
4.8 |
5.4 |
Single phase |
Three phase |
KW |
HP |
l/min |
0 |
10 |
20 |
30 |
40 |
50 |
60 |
70 |
80 |
90 |
MCP 100
|
MC 100 |
0.25 |
0.33 |
H
M
|
16 |
15 |
14 |
12.5 |
11 |
9 |
7 |
|
|
|
MCP 120 |
MC 120 |
0.30 |
0.40 |
19 |
18 |
17.5 |
16.5 |
15.5 |
14 |
12 |
10 |
|
|
MCP 130 |
MC 130 |
0.37 |
0.50 |
23 |
22 |
21 |
20 |
19 |
18 |
17 |
16 |
14 |
|
MCP 146 |
MC 146 |
0.60 |
0.80 |
28 |
27 |
26 |
25 |
23.5 |
22 |
20 |
18 |
16 |
|
MCP 158 |
MC 158 |
0.75 |
1 |
36 |
34 |
33.5 |
33 |
32.5 |
31.5 |
30 |
29 |
27 |
25 |
H=TOTAL
HEAD IN METERS. Q=FLOW RATE
 |
