Materials
Product wetted steel parts: acidresistant steel AISI 316Lor steel AISI 304
Other steel parts: stainless steel AISI 304
Outside surface: shot blast
Inside surface: bright, Ra0.4
Product wetted seals: EPDM rubber (temp less than 140°C), Viton or PTFE

Technical data
Max. Inlet pressure: 0.5MPa
Temperature range: -10°C to +180°C
Noise level (at 1m): <80dB (A)
Water pressure: max. 0.6 MPa
Water consumption: 0.2 - 1.0 L/min
Voltage and frequency: 3-, 50Hz, 220~240V/380~420V/660~690V, /Y
Motor power: 50Hz:0.75,1.1,1.5,2.2,3,4,5.5,7.5,11,15,18.5,22KW

Application
WCP series sanitary pump is applicable in conveying all kinds of liquid material
in the industries of dairy, beer, beverage, biochemical, fine chemical. It conveys not only
normal or middle viscous solutions but also suspension and corrosive liquids. WCP series
sanitary pumps has models of single state, single suction, open styled impeller and elaborate
design shell with reasonable and efficiency quality. Also the pump is designed for
CIP and SIP with emphasis on large internal rounding.

Standard design
WCP pump consist of a standard motor, impeller, pump casing, shaft and sanitary
mechanical seal. The WCP pump is designed for CIP clean system with cleanable seals.
The pump is cover with a stainless steel shroud for protection for motor and with four adjustable steel legs

Shaft seal
The WCP pump is equipped with either a single or a flushed shaft seal, both have stationary seal rings
in acid resistant steel AISI316L with sealing surface in carbon or carbide and rotating seal rings silicon
carbide. The secondary seal of the flushed seal is a long lasting lip seal. The WCP pump
may also be equipped with a double mechanical shaft seal.
